Droppers with smooth caps
 |
 |
 |
 |
 |
 |
 |
 |
| Europa 5 | GCMI 18/400 | GCMI 20/410 | GCMI 24/410 | ||||
| Single Skirt | Double Skirt | Single Skirt | Double Skirt | Single Skirt | Double Skirt | Single Skirt | Double Skirt |
Characteristics of smooth caps
| Cap Ring |
Ring | Europa 5 | GCMI 18/400 | GCMI 20/410 | GCMI 24/410 |
| Raw material | PP | ||||
| Outer dimensions | S.J : 20,06 x 19,4 D.J : 25,3 x 19,4 | S.J : 21,50 x 12 D.J : 26,10 x 12 | S.J : 23,50 x 16 D.J : 28,08 x 15,90 | S.J : 27 x 17,90 D.J : 32 x 18,1 | |
| Finishes | S S : Aluminium shell cap – D S : Different deep-vat-dyed colors, lacquering, metallisation, contouring hot stamping or on top | ||||
| Teat | Raw material | TPE / Caoutchouc | |||
| Teat flange | 15,2 | 18 | 21 | ||
| Pumping volume (ml) | 0,5 | ||||
| Height (mm) | 24 | ||||
| Bottle | Capacity (ml) | 15 – 30 – 50 | 15 – 30 – 50 | 30 – 50 | 30 – 50 – 100 |
S S : Single Skirt – D S : Double Skirt
Droppers with ribbed caps
 |
 |
 |
 |
| DIN 18 | PFP 18 | PFP 24 | PFP 28 |
Characteristics of ribbed caps
| Cap Ring |
Ring | DIN 18 | PFP 18 | PFP 24 | PFP 28 |
| Raw material | PP | ||||
| Outer dimensions | 21,50 x 14,50 | 20,60 x 12,80 | 26,10 x 17,10 | 29,50 x 17,20 | |
| Finishes | Different deep-vat-dyed colors | ||||
| Bottle | Capacity (ml) | 15 – 30 – 50 – 100 | |||
Characteristics of teats for ribbed caps
| Teat | DIN 18 | PFP 18 | PFP 18 (with security) |
PFP 18 Child resistant (with or without security) |
PFP 24 | PFP 24 Child resistant (with or without security) |
PFP 28 | PFP 28 (security ring) |
|||
| Raw material | Pumping volume (ml) | Height (mm) | Teat flange | ||||||||
| PVC / TPE | 0,6 | 22 | 16 | 16 | 16 | 16 | |||||
| 1 | 26,5 / 27,9 | 22 | 22 | 24,5 | 25,5 | ||||||
| Isopren Nitrile Butyl |
0,5 | 22,5 | 16 | 16 | 16 | 16 | |||||
| 0,75 | 23,2 | ||||||||||
| 1 | 26,4 / 25 / 27,3 |
22 | 22 | 25 | 25 | ||||||
| 1,5 | 33,8 | ||||||||||
| 2 | 37 / 38,8 | 25 | |||||||||
Pipettes
| Plastic pipettes | Glass pipettes | ||||||
 |
 |
 |
 |
 |
 |
 |
 |
| F8 | F16 | F8 | F13* | F16 | F18 | F19 | F21 |
* two possible hole widths
Characteristics of PP pipettes
| Shapes | Raw material | Lengths (mm) | Outer diameter | |
| F8 | Bout rond | Polyoléfine / PP | 57 | 7,25 |
| F16 | Forme effilée | 60 | 7,25 | |
Characteristics of glass pipettes
| Shapes | Raw material | Finishes | Lenghts (cm) | ||
| Diameter 7,25 | Diameter 9,25 | ||||
| F8 | NASALE Bout rond | Verre classe III | Black or white screen printing from 50 to 110 mm |
55 à 110 | |
| F13 | MATITA effilée | 55 à 110 | |||
| F13 | MATITA FORO LARGO Effilée trou large | 55 à 110 | |||
| F16 | MATITA COSMETICA Effilée cosmétique | 50 à 110 | 55 à 110 | ||
| F18 | PALLINA DIRITTA Bout boule droit | 55 à 110 | |||
| F19 | PALLINA RICURVA Bout boule courbé | 55 à 110 | |||
| F21 | PUNTA FRECCIA Bout grain de blé | 45 à 110 | |||
For specific lengths and diameters, please consult us.
Glass pipette protector
  |
Characteristics of the glass pipette protector
| Ring types | Raw material | Max. pipette length (mm) | |
| PFP 18 | PP | 70 | |
| PFP 24 | 80 | ||
